RS-485
| Use attributes for filter ! | |
| Available signals | A, B, C |
|---|---|
| Network topology | Point-to-point, multi-dropped, multi-point |
| Standard | ANSI/TIA/EIA-485-A-1998; Approved: March 3, 1998; Reaffirmed: March 28, 2003 |
| Maximum distance | Not specified |
| Connector types | Not specified |
| Maximum devices | At least 32 unit loads |
| Date of Reg. | |
| Date of Upd. | |
| ID | 2356222 |
About RS-485
RS-485, also known as TIA-485 or EIA-485, is a standard defining the electrical characteristics of drivers and receivers for use in serial communications systems. Electrical signaling is balanced, and multipoint systems are supported.
RS-485 Photos
